Product
2PNCT-SB, T-2PNCT-SB
Class 2 EP rubber insulated chloroprene rubber sheathed shielded flexible cables
Application
Power supply circuit of portable electrical machinery and apparatus not higher than 600V and in other cases where flexibility and bending resistance are required.
(It is not suitable for applications where it undergoes repeated bending)
Rated voltage:600V. Temp:80°C.
Feature
EP rubber for insulation.
Electrical characteristics, heat resistance, ozone resistance.
High allowable current.
Chloroprene rubber for sheath.
Abrasion resistance, oil resistance, flame retardance.
Conform to Electrical Appliance and Material Safety Law.
(8 cores or more is excluded)
Application
Power supply circuit of portable electrical machinery and apparatus not higher than 600V and in other cases where flexibility and bending resistance are required.
(It is not suitable for applications where it undergoes repeated bending)
Rated voltage:600V. Temp:80°C.
Feature
EP rubber for insulation.
Electrical characteristics, heat resistance, ozone resistance.
High allowable current.
Chloroprene rubber for sheath.
Abrasion resistance, oil resistance, flame retardance.
Conform to Electrical Appliance and Material Safety Law.
(8 cores or more is excluded)
| Category | Power |
|---|---|
| AWG | - |
| SQ（mm2） | 0.75 - 3.5 |
| Core (pair) | Multi |
| Use | Fix |
| Shield | Have |
| Voltage | 600V |
| Rating temperature | 80°C |
| Standards |
 |
| Characteristics | Oil, Heat, Wear |
