Product
HKIV LF
Heat-resistant polyvinyl chloride insulated wires for electorical apparatus
Application
Wiring of electrical machinery and apparatus not exceeding 600V.
Applications of high temperature location.
Rated voltage:600V. Temp:75°C.
Feature
Flexible annealed copper stranded conductor.
Use a heat-resistant PVC to insulation compared to KIV 1.2 times the allowable current.
Heat resistance75°C.
Reference to JIS C 3316.
0.75mm2~100mm2 wires conform to Electrical Appliance and Material Safety Law.
(0.5mm2 wires out of Electrical Appliance and Material Safety Law)
Application
Wiring of electrical machinery and apparatus not exceeding 600V.
Applications of high temperature location.
Rated voltage:600V. Temp:75°C.
Feature
Flexible annealed copper stranded conductor.
Use a heat-resistant PVC to insulation compared to KIV 1.2 times the allowable current.
Heat resistance75°C.
Reference to JIS C 3316.
0.75mm2~100mm2 wires conform to Electrical Appliance and Material Safety Law.
(0.5mm2 wires out of Electrical Appliance and Material Safety Law)
| Category | Signal and instrumentation, Power |
|---|---|
| AWG | - |
| SQ（mm2） | 0.5 - 200 |
| Core (pair) | Single |
| Use | Fix |
| Shield | None |
| Voltage | 600V |
| Rating temperature | 75°C |
| Standards |
 |
| Characteristics | Oil, Heat |
