Product
SUNLIGHT 3DX LF
PVC insulated oil flexible cord for electronics wiring
Application
AC 300V or less of the environmental type cable as machine tools,construction machinery, applications under harsh conditions, such as a robot power circuit.
Oil, flexibility of use.Rated voltage:300V. Temp:60°C.
Feature
Oil, heat, flame retardant and soft PVC for sheath.
Sheath material is non-migratory against ABS and PS resin.
Chemical, water, abrasion, cold resistance PVC for sheath.
Flame resisting : UL VW-1.
0.75mm2~5.5mm2 cables conform to Electrical Appliance and Material Safety Law.
(0.5mm2 cables used in less than 100V out of Electrical Appliance and Material Safety Law)
Application
AC 300V or less of the environmental type cable as machine tools,construction machinery, applications under harsh conditions, such as a robot power circuit.
Oil, flexibility of use.Rated voltage:300V. Temp:60°C.
Feature
Oil, heat, flame retardant and soft PVC for sheath.
Sheath material is non-migratory against ABS and PS resin.
Chemical, water, abrasion, cold resistance PVC for sheath.
Flame resisting : UL VW-1.
0.75mm2~5.5mm2 cables conform to Electrical Appliance and Material Safety Law.
(0.5mm2 cables used in less than 100V out of Electrical Appliance and Material Safety Law)
| Category | Signal and instrumentation, Power |
|---|---|
| AWG | - |
| SQ（mm2） | 0.5 - 2 |
| Core (pair) | Multi |
| Use | Fix |
| Shield | None |
| Voltage | 300V |
| Rating temperature | 60°C |
| Standards |
 |
| Characteristics | Oil |
