Product
STO(A)/TC LF
For tray cable, raceway and electronic equipment power supply cord
Application
Multi cable for North America.
Electric equipment cable with UL and cUL at 600V, 105°C.
(Category : QPOR, ZJCZ, ZKHZ, ZJCZ7)
Obtaining UL Listed STO, TC and MTW, this cable compliants to NFPA 70 and 79.
Feature
Heat resistant PVC material is used to insulation.
Oil, heat resistant and Flexible PVC sheath material is used.
It passes Vertical-Tray Flame Test of UL.
Application
Multi cable for North America.
Electric equipment cable with UL and cUL at 600V, 105°C.
(Category : QPOR, ZJCZ, ZKHZ, ZJCZ7)
Obtaining UL Listed STO, TC and MTW, this cable compliants to NFPA 70 and 79.
Feature
Heat resistant PVC material is used to insulation.
Oil, heat resistant and Flexible PVC sheath material is used.
It passes Vertical-Tray Flame Test of UL.
| Category | Power |
|---|---|
| AWG | 18 - 2 |
| SQ（mm2） | 0.75 - 30 |
| Core (pair) | Multi |
| Use | Fix |
| Shield | None |
| Voltage | 600V |
| Rating temperature | 105°C |
| Standards |
   |
| Characteristics | Oil, Heat |
